SCT3962 Series
SCT3962 series are replacement of Molex SPOX™ 3.96mm pitch Wire-to-Board Connectors.offers an extremely wide variety of mating configurations for pitch sizes from 2.50 to 5.08mm pitch.
Specification
| Series | SCT3962 Series |
|---|---|
| Contact Pitch | 3.96mm |
| No.of Contacts | 2 to 12 positions |
| Current | 5A (AWG #18 to #24) |
| Compatible | Cross Molex 5195-N Connector Series |
Previous
Next
Select Components
| Current Rating: | 5A |
| Voltage Rating: | 250V |
| Temperature Range: | -25°C~+85°C |
| Contact Resistance: | 20m Omega Max |
| Insulation Resistance: | 1000M Omega Min |
| Withstanding Voltage: | 1500V AC/minute |
Part No. Cross reference
| SCONDAR P/N | Molex P/N | Engineering P/N |
|---|---|---|
| SCT3962T-P | 08701031 | 5194T |
| SCT3962H-2P | 09501021 | 5195-02 |
| SCT3962H-3P | 09501031 | 5195-01 |
| SCT3962H-4P | 09501041 | 5195-04 |
| SCT3962H-5P | 09501051 | 5195-05 |
| SCT3962H-6P | 09501061 | 5195-06 |
| SCT3962H-7P | 09501071 | 5195-07 |
| SCT3962H-8P | 09501081 | 5195-08 |
| SCT3962H-9P | 09501091 | 5195-09 |
| SCT3962H-10P | 09501101 | 5195-10 |
| SCT3962H-11P | 09501111 | 5195-11 |
| SCT3962H-12P | 09501121 | 5195-12 |
| SCONDAR P/N | Molex P/N | Engineering P/N |
|---|---|---|
| SCT3962WV-2P | 09652028 | 5273-02A |
| SCT3962WV-3P | 09652038 | 5273-03A |
| SCT3962WV-4P | 09652048 | 5273-04A |
| SCT3962WV-5P | 09652058 | 5273-05A |
| SCT3962WV-6P | 09652068 | 5273-06A |
| SCT3962WV-7P | 09652078 | 5273-07A |
| SCT3962WV-8P | 09652088 | 5273-08A |
| SCT3962WV-9P | 09652098 | 5273-09A |
| SCT3962WV-10P | 09652108 | 5273-10A |
| SCT3962WV-11P | 09652118 | 5273-11A |
| SCT3962WV-12P | 09652128 | 5273-12A |
