SCT2548HIRA
Specification
| Part Name | Closed End IDC Housing |
| Pitch | 2.54mm |
| Series | SCT2548 |
| Compatible | TE MTA-100 640440 Series |
Part No. Cross Reference
| SCONDAR P/N | TE P/N | TE P/N | TE P/N | TE P/N | Circuits |
|---|---|---|---|---|---|
| SCT2548HIRA-02Cxx | 3-640440-2 | 3-640441-2 | 3-640442-2 | 3-640443-2 | 2 |
| SCT2548HIRA-03Cxx | 3-640440-3 | 3-640441-3 | 3-640442-3 | 3-640443-3 | 3 |
| SCT2548HIRA-04Cxx | 3-640440-4 | 3-640441-4 | 3-640442-4 | 3-640443-4 | 4 |
| SCT2548HIRA-05Cxx | 3-640440-5 | 3-640441-5 | 3-640442-5 | 3-640443-5 | 5 |
| SCT2548HIRA-06Cxx | 3-640440-6 | 3-640441-6 | 3-640442-6 | 3-640443-6 | 6 |
| SCT2548HIRA-07Cxx | 3-640440-7 | 3-640441-7 | 3-640442-7 | 3-640443-7 | 7 |
| SCT2548HIRA-08Cxx | 3-640440-8 | 3-640441-8 | 3-640442-8 | 3-640443-8 | 8 |
| SCT2548HIRA-09Cxx | 3-640440-9 | 3-640441-9 | 3-640442-9 | 3-640443-9 | 9 |
| SCT2548HIRA-10Cxx | 4-640440-0 | 4-640441-0 | 4-640442-0 | 4-640443-0 | 10 |
| SCT2548HIRA-11Cxx | 4-640440-1 | 4-640441-1 | 4-640442-1 | 4-640443-1 | 11 |
| SCT2548HIRA-12Cxx | 4-640440-2 | 4-640441-2 | 4-640442-2 | 4-640443-2 | 12 |
| SCT2548HIRA-13Cxx | 4-640440-3 | 4-640441-3 | 4-640442-3 | 4-640443-3 | 13 |
| SCT2548HIRA-14Cxx | 4-640440-4 | 4-640441-4 | 4-640442-4 | 4-640443-4 | 14 |
| SCT2548HIRA-15Cxx | 4-640440-5 | 4-640441-5 | 4-640442-5 | 4-640443-5 | 15 |
| SCT2548HIRA-16Cxx | 4-640440-6 | 4-640441-6 | 4-640442-6 | 4-640443-6 | 16 |
| SCT2548HIRA-17Cxx | 4-640440-7 | 4-640441-7 | 4-640442-7 | 4-640443-7 | 17 |
| SCT2548HIRA-18Cxx | 4-640440-8 | 4-640441-8 | 4-640442-8 | 4-640443-8 | 18 |
| SCT2548HIRA-19Cxx | 4-640440-9 | 4-640441-9 | 4-640442-9 | 4-640443-9 | 19 |
| SCT2548HIRA-20Cxx | 5-640440-0 | 5-640441-0 | 5-640442-0 | 5-640443-0 | 20 |
| SCT2548HIRA-21Cxx | 5-640440-1 | 5-640441-1 | 5-640442-1 | 5-640443-1 | 21 |
| SCT2548HIRA-22Cxx | 5-640440-2 | 5-640441-2 | 5-640442-2 | 5-640443-2 | 22 |
| SCT2548HIRA-23Cxx | 5-640440-3 | 5-640441-3 | 5-640442-3 | 5-640443-3 | 23 |
| SCT2548HIRA-24Cxx | 5-640440-4 | 5-640441-4 | 5-640442-4 | 5-640443-4 | 24 |
| – | 5-640440-5 | 5-640441-5 | 5-640442-5 | 5-640443-5 | 25 |
| – | 5-640440-6 | 5-640441-6 | 5-640442-6 | 5-640443-6 | 26 |
| – | 5-640440-7 | 5-640441-7 | 5-640442-7 | 5-640443-7 | 27 |
| – | 5-640440-8 | 5-640441-8 | 5-640442-8 | 5-640443-8 | 28 |
