SCONDAR SCT1506T – 1.5 mm Pitch Crimp Terminal for High‑Reliability Wire‑to‑Board Connections

Введение

Сайт SCONDAR SCT1506T is a precision‑manufactured crimp terminal designed for use with 1.5 mm pitch wire‑to‑board housings such as the SCT1506H series. Engineered to support high‑density board designs, this terminal delivers a secure lock interface, low insertion force, and stable electrical performance. When combined with compatible housings, it provides a highly reliable connection with a positive tactile clicking sensation.

Key Specifications

Designed for Secure Lock Mechanism

The SCT1506T is engineered to work seamlessly with housings that feature a secure lock mechanism. The terminal’s geometry ensures proper engagement with the housing’s lock system, providing a positive tactile click when fully inserted. This locking action prevents accidental pull‑out due to vibration or wire tension, ensuring a highly reliable connection throughout the product’s life.

Exceptionally Easy to Assemble

Despite its robust design, the SCT1506T offers low insertion force during both crimping and housing insertion. The terminal slides smoothly into the housing cavity, reducing operator fatigue and improving assembly efficiency. The clear tactile feedback upon full seating confirms correct installation, minimizing assembly errors.

Large Outer Lock Compatibility

When used with housings that incorporate a large outer lock design, the SCT1506T benefits from the extra assurance in both lock and lock‑release functions. The terminal remains securely retained while allowing easy disconnection when needed, without damage to the contact or housing.

Prevention of Incorrect Mating

The SCT1506T is designed with polarization features that complement the housing’s incorrect mating prevention system. The terminal can only be inserted in the correct orientation, eliminating the risk of reverse insertion and ensuring proper electrical contact every time.

Robust Material for Demanding Environments

The terminal is stamped from phosphor bronze with a material thickness of 0.15 mm. Phosphor bronze offers excellent strength, conductivity, and fatigue resistance – ideal for repeated mating cycles and reliable crimp termination. The tin‑plated finish provides good solderability, corrosion protection, and stable contact performance in standard operating environments.

Wide Wire Range

The SCT1506T accepts discrete wires from 24 AWG to 30 AWG, covering a broad spectrum of common wire gauges used in consumer electronics, home appliances, industrial equipment, and LED lighting. This flexibility simplifies inventory management across different product lines.

Compatible with High‑Volume Automated Crimping

The SCT1506T is designed for use with standard automatic crimping machines and applicators. Please contact SCONDAR for detailed crimp specifications, strip length recommendations, and tooling information.

Области применения

The SCONDAR SCT1506T is ideal for high‑density wire‑to‑board connections in:

• Потребительская электроника – Portable audio, digital cameras, gaming devices

• Home appliances – Air conditioners, washing machines, smart home controllers

• Industrial equipment – Sensors, small control panels, power supplies

• Светодиодное освещение – Strip lighting, driver modules

• Автомобили – Interior electronics (non‑safety critical)

Why Choose SCONDAR SCT1506T?

• High current rating – 2 A per contact

• Wide wire range – 24 AWG to 30 AWG

• Low contact resistance – ≤20 mΩ initial, ≤40 mΩ after environmental testing

• Wide operating temperature – -40°C to +105°C

• Phosphor bronze construction – strong, conductive, and fatigue‑resistant

• Tin‑plated finish – reliable solderability and corrosion protection

• Secure lock compatible – works with housings featuring positive locking

• Low insertion force – easy assembly, reduces operator fatigue

• RoHS compliant – manufactured under strict quality control

Заключение

The SCONDAR SCT1506T crimp terminal delivers reliable, high‑performance wire termination for 1.5 mm pitch wire‑to‑board connectors. With its 2 A current rating, 24–30 AWG wire range, phosphor bronze construction, and compatibility with secure lock housings, it provides engineers with a dependable interconnect solution for high‑density board designs. Whether you are designing new equipment or seeking a robust second source, the SCT1506T offers the quality and performance you need.
